GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 25
SpecialFeaturesControls
INTENSITY‐Thisknobadjuststheintensityofyourtrace.
PushingthebuttontogglesbetweenWaveStreamfast
viewingmodeandrealtimemode.
W
AVESTREAMLAMP‐Thislamplightswhenthe
oscilloscopeisdisplayinginWaveStreamfastviewing
mode.
C
URSORTYPE‐Thispushbuttonturnsonthecursors,then
cyclesthroughthefourdifferentcursortypeswitheach
additionalpush:
ADJUSTFINE‐Thisdualfunctionknobcontrolsthe
placementofthetoporleftcursor.Whentheknobisin
Cursormode,theCURSlampislit.
Whenyouclickinanydataentryfieldinanydialog,theknob
automaticallyswitchesfromcursorplacementmodeto
adjustmentmode,andtheADJlamplights.Thisallowsyo
uto
dialinfinegrainedvalues.Whenyouclosethedialog,the
knobrevertstocursorplacementmode.
A
DJUSTCOARSE‐Thisdualfunctionknobcontrolstheplacementofthebottom
orrightcursor.WhentheknobisinCursormode,theCURSlampislit.
Whenyouclickinanydataentryfieldinanydialog,theknobautomatically
switchesfromcursorplacementmodetoadjustmentmode,andtheADJlamp
lights.Thisallowsyoutodialinco
arsegrainedvalues.Whenyouclosethe
dialog,theknobrevertstocursorplacementmode.
