• DCGainAccuracy:±1.0%offullscale(typical):
±1.5% >/=10mV/div
±2.5% 5mV/div
±3.5% 2mV/div
• OffsetRange:
44Xi‐A,MXi‐A 64Xi‐A,MXi‐A 62Xi‐A,MXi‐A 104Xi‐A,MXi‐A 204Xi‐A,MXi‐A
50Ω:±1V@2–98mV/div,±10V@100mV/div–1
V/div;1MΩ:±1V@2–98mV/div,±10V@100
mV/div–1V/div,±100V@1.02V/div–10V/div
50Ω:±400mV@2–
4.95mV/div,±1V@5–99mv/div,±10
V@100mV–1V/div,1MΩ:±400
mV@2–4.95mV/div,±1V@5–99
mV/div,±10V@100mV–1V/
div,
±100V@1.02–10V/div
• OffsetAccuracy:±(1.5%ofoffsetvalue+0.5%offullscalevalue+1mV)
• WR104and204,Xi‐AandMXi‐AModels:±(1.5%ofoffsetvalue+1.0%offull
scalevalue+1mV)
• ProbingSystem:BNCorProBus
Horizontal System
• Timebases:Internaltimebasecommontoallinputchannels;anexternalclock
canbeappliedattheauxiliaryinput
• Time/divRange:Realtime:200ps/divto10s/div,RISmode:200ps/divto
10ns/div(WR104MXi‐A,WR104Xi‐A,WR204Xi‐A:100ps/divto10ns/div),Roll
mode:upto1,
000s/div
• Math&ZoomTraces:4math/zoomtracesstandard
• ClockAccuracy:</=5ppmat25°C(</=10ppmat5to40°C)
• JitterNoiseFloor:3psrmstypical(WR204Xi‐A,MXi‐A)
• TimeIntervalAccuracy:ClockAccuracy+Ji
tterNoiseFloor
• SampleRate&DelayTimeAccuracy:equaltoClockAccuracy
• Channel‐to‐ChannelDeskewRange:±9xtime/divsetting
• InterpolatorResolution:1.2ps


