GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 19
considerablylargerthanthe
oscilloscope’smonitor,youmay
wanttomakeittheprimary
device.
7. Themonitornotselectedas
primaryisautomaticallyshownin
theSecondaryDevicebox.
This setting determines mouse
pointer movement from one
monitor to the other.
8. Draganddropthemonitoricons
asdesired.Forexample,ifthe
secondarymonitor(2)isleftof
theprimarymonitor(1),the
monitor2iconshouldbeplaced
totheleftofthemonitor1icon.
Themonitorsmayalsobeplaced
ontopoftheothertoarrange
themvertically.
9. ClickDisplaySettingsandsetthe
resolution(screenarea)andcolor
palettefortheexternalmonitor.
CAUTION
Donotchangethesesettingsforthe
Notebook(oscilloscope)monitorinorder
tomaintainproperoscilloscopedisplay
functionality.
10. ClickOK.
PROBES
YourWaveRunnerXioscilloscopeissuppliedwithonepassiveprobeforeach
channel.Thesuppliedpassiveprobehasahighinputresistanceandlow
capacitancemakeitidealforgeneralpurposeprobingofsignalswithfrequency
contentfromDCthroughseveralhundredMHz.Thesuppliedpassiveprobehasa
largeselectionofco
nnectionaccessories,suppliedstandardwiththeprobeand
availablefromLeCroyasoptionalaccessories.
