GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 85
Setting Up Mask Testing
1. TouchAnalysisÆ Pass/FailSetup…from
themenubar.
2. TouchaQtab.Asetupdialogforthepositionisshown.
3. TouchinsidetheSource1fieldandselectasourcefromthepopupmenu.
4. TouchinsidetheConditionfieldinthemaindialogandselectMaskTest.
5. FromtheTestminidialog,makeaselectionintheTe
stisTruewhengroup
ofbuttons.
6. Thisselectionmeans,forexample,thatifyouselectAllIn,thetestisFalse
ifevenasinglewaveformfallsoutsidethemask.
