WAVERUNNER Xi-A AND MXi-A SERIES
34 WRXi-A-GSM-E Rev A
TURNINGONTRACES
1. Turnonachanneltrace bypushinga
frontpanelchannelselectbutton
(displayingthetracelabelforthe
correspondinginputchannel).Whilethis
turnsonthetrace,itleavesthecurrent
dialogdisplayed.
Ifyouwanttoalsodisplaythevertical
setupdialogforthechanneltrace,touch
thetracelabeltwice.Thefirsttouch
activatesth
echannel,whilethesecond
opensitssetupdialog.Theappearanceof
theselectedtracelabelbecomesasolid
colorwhenactive:
2. Turnonamathfunctiontrace by
touchingMathÆMathSetup...onthe
dropdownmenu.TouchtheOn
checkboxforthetraceyouwantto
activate.
3. Youcanalsoturnontracesformath
functions,parameters,andmemory
traceswithoutleavingtheVerticalAdjust
dialogbytouchingtheiconsatthe
bottomoftheVerticalAdjustdialog.
