WAVERUNNER Xi-A AND MXi-A SERIES
28 WRXi-A-GSM-E Rev A
ZeroVoltsLevel‐Thisindicatorislocatedatthe
leftedgeofthegrid.Changethezerovoltslevelby
turningtheV
ERTICALOFFSETknob.Pushtheknobto
resettheindicatortothemiddleofthegrid.
TraceDescriptors
Verticalandhorizontaltracedescriptorlabelsaredisplayedbelowthegrid.They
provideasummaryofyourchannel,timebase,andtriggersettings.Adjustthese
settingsbytouchingtherespectivelabel(itscorrespondingsetupdialogisthen
shown).
Channeltracelabelsshowtheverticalsettingsforthe
trace,aswellascursorinformationifcursorsareinuse.
Inthetitlebarofthelabelarealsoincludedindicators
for(SinX)/Xinterpolation,waveforminversion(INV),
deskew(DSQ),coupling,bandwidthlimiting(BWL),and
averaging(AVG).Theseindicatorshavealongan
dshort
form:
Besideschanneltraces,mathandmemorytracelabels
arealsodisplayed.Labelsaredisplayedonlyfortraces
thatareturnedon.
Asavisualaid,anactivechannel(i.e.,theonewhose
settingscanbeadjustedbythefrontpanelknobs)is
displayedinsolidcolor.
ThetitlebaroftheTimeBase labelshowsthetrigger
delaysetting.Timeperdivisionandsampling
informationisgivenbelowthetitlebar.
ThetitlebaroftheTriggerlabelshowsthetrigger
mode:Auto,Normal,orStopped.Belowthetitlebaris
giventhecoupling(DC),triggertype(Edge),source
(C1),level(0mV),andslope(Positive).
ShownbelowtheTimebaseandTriggerlabelsisvalue
informationforhorizontalcursors,includingthetime
betweencursorsandthefrequency.
