GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 115
• histogramof1,000events
• integral
• invert(negate)
• zoom(identity)
Measure Tools (standard)
Display any 8 parameters together with statistics, including their average,
high, low, and standard deviations. Histicons provide a fast, dynamic view of
parameters and wave shape characteristics.
• amplitude
• area
• base
• cycles
• delay
• deltadelay
• deltatime@level
• Dtrigtime
• duration
• dutycycle
• falltime(90‐10%,80‐20%,@level)
• first
• frequency
• last
• level@x
• MATLABparam
• maximum
• mean
• median
• minimum
• numberofpoin
ts
• overshoot+
• overshoot‐
• peak‐to‐peak
• period
• phase
• risetime(10‐90%,20‐80%,@level)
• rms
• std.deviation
• time@level
• top
• width
• widthnegative
•
x@minimum
• x@maximum
