GETTING STARTED MANUAL

WRXi-A-GSM-E Rev A 37

UsingWaveStreamFastViewingMode

Adjusting Trace Intensity

TheINTENSITY knobadjuststhebrightnessof

yourtrace.Pushingthebuttontogglesbetween

WaveStreamfast‐viewingmodeandreal‐time

mode.

TIMEBASESETUP

SetupthetimebasebyusingthefrontpanelHorizontal

controls,justasforanalogoscilloscopes.
