GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 31
Coupling
Couplingchoicesareasfollows:
DC50Ω
GROUND
DC1MΩ
AC1MΩ
SelectcouplingbytouchinginsidetheCouplingfieldandchoosingacouplingmode
fromthepopupmenu.
Note:ThecouplingchoicesforachannelchangeifaProBusprobeisconnectedtoa
channel.
Deskew
Deskewallowsyoutocompensatefordifferentlengthsofcables,probes,or
anythingelsethatmightcausetimingmismatchesbetweensignals.Connectall
probestothedesiredchannels,thenprobeacommonsignalwitheachprobeand
adjustfortimingdifferencesusingDeskew.
ProbeAttenuation
IfyouuseaLeCroyProBuscompatibleactiveprobe,oraprobecompatiblewith
ProbeRing,theattenuationisautomaticallysetbytheoscilloscope.Ifitisnot
automaticallyset,selectavalueherebytouchinginsidetheProbeAttenfield
selectingavaluefromthepopupmenu.
BandwidthLimiting
Youmaysometimeswanttolimithighfrequencynoiseonaverylowbandwidth
inputsignal.Ifthisisthecase,youcanlimitthechannelbandwidthtolessthanthe
fullbandwidthoftheoscilloscope.Selectadifferentbandwidthbytouchinginside
theBandwidthfieldandselectingavaluefromthepopupmenu.
AveragingYourSignal
TheWaveRunnerXiAoscilloscopeallowsyoutheopportunitytocontinuously
averageyoursignaltoreducesignalnoiseandaidinsignalevaluation.Ifyouwant
touseaveraging,selectavalueherebytouchinginsidetheAveragingfieldand
enteringavalueupto1millionsweepsonthepopupkeypad.
