GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 27
ThisbuttonappearsaftertheAutoSetupfrontpanelbuttonispressed,andafter
Zooming.IfyouwanttoperformanUndooperation,itmustbetheverynext
operationafteryouperformtheAutosetuporZoomoperation.
GridArea
Thegridareaisdividedinto8verticaldivisionsand10horizontaldivisionsjustlike
anyotheroscilloscope.Thereareseveralindicatorsonthegridtohelpyou
understandthefollowing:
TriggerDelay‐Thisindicatorislocatedalongthe
bottomedgeofthegrid.Triggerdelayallowsyou
toseethesignalpriortothetriggertime.
Alltriggerdelayvalues(includingposttrigger
delay,shownhere)aredisplayedintheTimebase
DescriptorLabel.Zerodelayisthehorizontal
centeroftheoscilloscopedis
play.
Thedefaultsetting(Time)isforthedelaytobe
readoutinseconds,andtomoveproportionately
whenthetimebaseknobisturned.Ifyouwantto
setdelay(Div)toafixedpositiononthegridand
thenhaveitstayfixedasthetimebasech
anges,go
toUtilities,Preferences,Acquisition.
PosttriggerDelay‐Thisisindicatedbyaleft
pointingarrowbelowleftofthegrid.Pretrigger
delayisindicatedbyarightpointingarrowbelow
rightofthegrid.
TriggerLevel‐Thisindicatorislocatedattheright
edgeofthegrid.Ittracksthetriggerlevelasyou
repositionthetraceupordown,orchangescale.
Whentriggeringisstopped,ahollowarrow
indicateswherethenewlevelendsupwhen
triggeringresumes.
PushtheL
EVELknobtoresetthelevelto50%.
