GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 75
ManagingFiles
Usetheinstrument'sutilitiestocreatewaveformfilesonoptionalfloppydisk,
internalharddrive,ornetworkdrives.
Hard Disk Partitions
Theinstrument'sharddiskispartitionedintodriveC:anddriveD:.DriveC:contains
theWindowsoperatingsystemandtheinstrumentapplicationsoftware.DriveD:is
intendedfordatafiles.
DOCUMENTINGYOURWORK
TheWaveRunnerXiLabNotebookfeaturesimplifiesthewaywaveforms,screen
captures,andoscilloscopesetupfilesaresavedanddocumented.LabNotebookalso
providesaneasywaytorecallyoursettingswiththeFlashbackfeature.Anditlets
youcreatereports,showingyourscreenimages,inpdf,html,orrtfoutputformats.
CreatingaLabNotebookEntry
LabNotebookentriesareeasilycreated
byselectingLabNotebookfromtheFile
menu,thenclickingtheCreatebutton.
Severalannotationtoolsandcolorsare
thenputatyourdisposaltomarkup
yourwaveform.WhenyouclickDone,
yourmarkupsandoscilloscopesettings
aresavedtogetherinadatabase
residentontheinstrument.
ClicktheCreateReport buttonto
generateahardcopyformatthatyou
cansavetoanetworkdriveorexternal
media.OrclicktheEmailbuttonto
sendthereporttoanotherlocation.Use
theFlashbackfeatureatanytimeto
recallaNotebookentry,including
oscilloscopesetup,forfurtherstudy.
