GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 61
Sequence Mode Display
SetupaSequenceModedisplaybyfirstenablingSequencemodeintheTimebase
Horizontaldialog.ANumSegmentsvaluemustalsobeprovidedasfollows:
1. TouchtheTimebasedescriptorlabel.
2. IntheTimebase dialog,touchthe
Sequencemodebutton.
3. SelecttheSequence tab.Under
AcquisitionSettings,touchinsidethe
NumSegmentsfieldandenteravalue
from2to500.
4. UnderTouchinsidetheTimeoutfield
andenteravaluefrom10msto100s.
ThenchecktheEnableTimeout
checkbox.
5. UnderDisplaySettings,touchinsidethe
DisplayModefieldandselectamode
fromthepopupmenu.
Note:ThemaximumvaluethatyoucanenterforStartingatdependsonthe
NumSegmentsvalueyouenteredunderAcquisitionSettings.Italsodependson
theNumSegDisplayedvalueyouentered.Forexample,ifyouhadentereda
valueof500inNumSegments,andavalueof10inNumSegDisplayed,the
maximumvalueyoucanenterasastartingsegmentis491sothat10segments
canbeseen.
