WAVERUNNER Xi-A AND MXi-A SERIES
114 WRXi-A-GSM-E Rev A
SerialPort:DB9COM1port(notforremotecontrolofoscilloscope)
Auxiliary Input
Signal Types: Select External Trigger or Clock input on front panel.
Auxiliary Output
SignalTypes:Selectfromcalibratorsignalonfrontpanelorcontrolsignals
outputfromrearpanelBNC.
CalibratorSignal:250Hzto1MHzsquarewaveorDClevel;50mVto1.0V
(selectable)into1kohms
ControlSignals:triggerenabled,triggerout,pass/failstatus,oroff
Math Tools (standard)
Display up to four math function traces (F1 to F4). The easy-to-use graphical
interface simplifies setup of up to two operations on each function trace.
Function traces can be chained together to perform math-on-math.
absolutevalue
average(summed)
average(continuous)
copy
derivative
deskew(resample)
difference()
enhancedresolution(to11bits
vertical)
envelope
exp(basee)
exp(base10)
fft(powerspectrum,magnitude,
phase)
floor
ln(logbasee)
log(base10
)
MATLABmath
product(X)
ratio(/)
reciprocal
rescale(withunits)
roof
segment
segment
(sinx)/x
square
squareroot
sum(+)
trend(datalog)of1,000events
