WAVERUNNER Xi-A AND MXi-A SERIES
84 WRXi-A-GSM-E Rev A
6. TouchinsidetheConditionfieldintheParamComparemini‐dialogand
selectamathoperatorfromthepop‐upmenu.

7. TouchinsidetheLimitfieldandenteravalue,usingthepop‐upnumeric
keypad.Thisvaluetakesthedimensionsoftheparameterthatyouare
testing.Forexample,ifyouaretestingatimeparameter,theunitis
seconds.IfyouchoseeitherWithinDeltaPctorWithinDeltaAbsfromthe
Conditionmenu,youalsohav
ethechoiceofsettingthelimitbymeansof
thestatisticalbuttonsatthebottomoftheParamComparedialog:

Comparing Dual Parameters
SetupDualParameters byfollowingthepreviousstepsin
theComparingaSingleParametertopic,exceptyou
selectingtheDualParamComparecondition.
