WAVERUNNER Xi-A AND MXi-A SERIES
24 WRXi-A-GSM-E Rev A
VerticalControls
OFFSET‐Adjuststheverticaloffsetofachannel.
V
OLTS/DIV‐AdjuststheVolts/Divisionsetting(vertical
gain)ofthechannelselected.
C
HANNELBUTTONS‐IfthechannelisalreadyON,the
channelbuttonmakesthechannelactive.Ifthe
channelisOFF,thechannelbuttonturnsthechannel
ON.Whenthechannelisactive,thechannelbuttonis
lit,andtheOffsetandVolts/Divknobsarededicated
tothatchannel.
ZoomCon
trolKnobs
QUICKZOOM‐Automaticallydisplays
magnifiedviewsofuptofoursignalinputson
multiplegrids.Withfourinputsignals,thesignals
aredisplayedalongwithfourzoomtraces,each
onitsowngrid.Thisbuttonturnsoffallother
tracesandredefinesallmathfunctionstobe
zoomsofchannels.
POSITION‐Adjuststhehorizontalposition
ofazoomtraceonthedisplay.Thezoomregionis
highlightedincoloronthesourcetrace.Unlike
Delay,thepositionisnotcalibratedtothetrigger
position.
ZOOM‐Adjuststhehorizontalzoom(magnificationfactor)ofthe
selectedzoomtrace.
POSITION‐Adjuststheverticalpositionoftheselectedzoomtraceonthe
display.UnlikeOffset,thepositionisnotcalibratedtothe0Vreference.
ZOOM‐Adjuststheverticalzoom(magnificationfactor)oftheselected
zoomtraceonthedisplay.
INDICATOR LAMPS‐Thethreelampsatthebottomofthepanelarelitaccording
tothekindoftraceyouarezooming,orwhosepositionyouareadjusting:
channeltrace,mathtrace,ormemorytrace.Theexacttracethatisactivehasa
solidlycoloreddescriptorlabel.
