4. UnderOffsetSettingconstantin:,toucheithertheVoltsorDivbutton.
5. UnderDelaySettingconstantin:,toucheithertheTimeorDivbutton.
Trigger Counter
CheckingtheResettriggercounterbeforestartinganewacquisitioncheckbox
clearsthetriggercountereachtimetheoscilloscopeissuesanarmacquisition
command.

ThisapplieswhenyouhavesetatriggerHoldoffconditionintheTriggerdialogin
eithertimeorevents:
Thedefaultconditionofthiscontrolisoff(unchecked).
E-mail
Beforeyoucansende‐mailfromtheoscilloscope,itmustfirstbeconfigured.
1. TouchUtilitiesÆPreferenceSetup…fromthemenubar.
2. TouchtheE‐mailtab.
3. Chooseane‐mailserverprotocol:MAPI(MessagingApplication
ProgrammingInterface)istheMicrosoftinterfacespecificationthatallows
differentmessagingandworkgroupapplications(
includinge‐mail,voice
mail,andfax)toworkthroughasingleclient,suchastheExchangeclient
includedwithWindows95andWindowsNT.MAPIusesthedefault
Windowse‐mailapplication(usuallyOutlookExpress).SMTP(SimpleMail
TransferProtocol)isaTCP/IPprotocolforsendingmessagesfromone
compu
tertoanotherthroughanetwork.Thisprotocolisusedonthe
Internettoroutee‐mail.Inmanycasesnoaccountisneeded.
