LeCroy WaveRunner Xi-A User Manual

GETTING STARTED MANUAL
WRXi-A-GSM-E Rev A 53
• Zoomviewallowsyoutoexpandawaveformfeatureverticallyand
horizontally.Thiscanbeusedtoapplyfurtherprocessing,tostoreit,orto
applyadescriptivelabeltothefeature.
• ScanHistogramprovidesastatisticalviewofedgesmeetingyoursearch
criteria.
• ScanOverlayplacesallca
pturededgesoneontopoftheotherinaseparate
grid.Youcanapplypersistenceinthisview.
Note:Thenumberofgridsdisplayedvariesfromonetothreegridsdependingon
whichviewsareenabled.WaveScanhandlesthisfunctionautomatically,and
thereisnooptiontomovetracesfromonegridtoanother,aswouldbethecase
undernormal(non‐WaveScan)operation.
