Viva Series, TPS Settings 47
Description of fields
Next step
Page changes to the Relative page.
Turn Instrument to Hz/V,
Relative page
The values are added to the current telescope position to calculate the new direction for the
telescope to turn to.
Description of fields
Next step
Press OK. The instrument turns to the prism.
For Target aiming: Automatic an ATR measurement is performed. If no prism was found, the
instrument turns to the position typed in.
For Target aiming: Lock the instrument locks on the prism and the LOCK icon is displayed.
If no prism was found, the instrument turns to the position typed in.
Field Option Description
Azimuth Editable field Oriented horizontal direction for the instrument to
turn to.
V angle Editable field Vertical direction for the instrument to turn to.
Field Option Description
ΔHz Editable field Angular difference for the horizontal angle to turn
to.
ΔV Editable field Angular difference for the vertical angle to turn to.
