Viva Series, TPS Settings 49
Compass reading: The horizontal angle read from the compass while aiming to
the instrument.
V angle: If the compass works as a clinometer, those values can also be used.
)
The horizontal and vertical angle reads from the compass are always
displayed in degree regardless of the system settings.
9. OK to return to the survey screen. The instrument turns to the prism.
For Target aiming: Automatic an ATR measurement is performed. If no prism was
found, the instrument turns to the position typed in.
For Target aiming: Lock the instrument locks on the prism and the LOCK icon is
displayed. If no prism was found, the instrument turns to the position typed in.
Step Description
