Viva Series, COGO 877
Description of columns
Next step
Highlight the COGO inverse calculation of which a result is to be taken over.
OK. The relevant result of the highlighted COGO inverse calculation is copied into the field
which was initially highlighted on the Input page.
View To view all calculated values for the highlighted COGO inverse calculation.
Includes the height difference, the slope distance, the grade and the
coordinate differences between the two known points.
Delete To delete the highlighted COGO inverse calculation.
More To display other information in the third column.
Fn Quit To exit COGO calculation.
Column Description
From The point ID of the first known point for the COGO inverse calculation.
To The point ID of the second known point for the COGO inverse calculation.
Azimuth The direction from the first to the second known point.
HDist The horizontal distance between the two known points.
Date and Time When the COGO inverse calculation was stored.
Key Description
To Next Page
