13.1.2.4 Display of status words on keypad
Some diagnoscs parameters contain bit-coded status words. Each single bit has a certain
meaning.
Display of 16-bit status words on the keypad
MAN AUTO SETLOC REM
b.0000.0000.0000.0100
0 0 x o O O 4
Bit 15 Bit 0
①
Hexadecimal value
Display of 32-bit status words on the keypad
MAN AUTO SETLOC REM
b.0000.0000.0000.0001
H W X o O O 1
Bit 31 Bit 16
MAN AUTO SETLOC REM
b.0000.0000.0000.0000
L W X o O O O
Bit 15 Bit 0
①
Hexadecimal value High word (HW)
②
Hexadecimal value Low word (LW)
Using accessories
K
eypad
Keypad parameterisaon mode
