Lenze i410 - Process Controller Sleep Mode

7.3.2 Process controller sleep mode
If the PID control is acvated, this funcon sets the drive in process controller mode to an
ener
gy-saving sleep mode when no power is required.
Details
A typical applicaon for this funcon is a booster pump for water in a high-rise building. If no
tenant opens the water tap or uses the shower for a longer period of me, the pump changes
to the energy-saving sleep mode. This usually happens at night. Thesleep mode automacally
ends as soon as a tenant opens the tap again. The pumps operates normally again unl the
condion for the sleep mode is pending again.
The condions for acvang and terminang the sleep mode can be set independently of one
another in 0x4023:001 (P610.01) and 0x4023:006 (P610.06) (see the following tables).
In 0x4023:005 (P610.05), a delay me can be set for the acvaon. This is the minimum me
the values must fall below or exceed the respecve threshold before the sleep mode is
acvated.
0x4023:001
(P610.01)
Condion for acvang the sleep mode
0 Sleep mode deacvated.
1
Frequency setpoint
<
Frequency threshold
( +
Delay
me
)
0x2B0E (P102.00) 0x4023:003 (P610.03) 0x4023:005 (P610.05)
2
Frequency setpoint
<
Frequency threshold
( +
Delay me
)
0x2B0E (P102.00) 0x4023:003 (P610.03) 0x4023:005 (P610.05)
OR
Current process variable
>
Feedback threshold
( +
Delay me
)
0x401F:002 (P121.02) 0x4023:004 (P610.04) 0x4023:005 (P610.05)
3
Frequency setpoint
<
Frequency threshold
( +
Delay me
)
0x2B0E (P102.00) 0x4023:003 (P610.03) 0x4023:005 (P610.05)
OR
Current process variable
<
Feedback threshold
( +
Delay me
)
0x401F:002 (P121.02) 0x4023:004 (P610.04) 0x4023:005 (P610.05)
0x4023:006
(P610.06)
Condion for terminang the sleep mode
0
Frequency setpoint
>
Frequency threshold
( + 2 Hz hysteresis )
0x2B0E (P102.00) 0x4023:003 (P610.03)
OR
PID error value
>
Bandwidth
0x401F:007 0x4023:007 (P610.07)
1
Current process variable
<
Recovery threshold
0x401F:002 (P121.02) 0x4023:008 (P610.08)
2
Current process variable
>
Recovery threshold
0x401F:002 (P121.02) 0x4023:008 (P610.08)
Conguring the frequency control
Conguring the process controller
Pr
ocess controller sleep mode
105
