14.5.2 Error conguraon
The errors can be divided into two types:
•
Err
ors with predened error type
•
Errors with congurable error type
Especially crical errors are permanently set to the "Fault" error type in order to protect
inverter and motor from damages.
In case of errors with congurable error type, the default seng can be changed in
consideraon of safety aspects and the operaonal performance. The selecon "No response
[0]" is, however, only available for minor errors.
The "Error codes, causes and remedies" table lists the error type for each error. If the error
type can be congured by the user, the "adjustable in" column displays the corresponding
parameter. ^ 290
14.5.3 Error reset
If the error condion is not acve anymore, there are several opons to reset an acve error
and thus leave the error state again:
•
Via the keypad key
. 4Err
or reset with keypad ^ 247
•
Via the trigger assigned to the "Reset fault" funcon.
•
Via the buon
in the »EASY Starter« ("Diagnoscs" tab).
Notes:
•
Cert
ain errors can only be reset by mains switching.
•
Certain errors (e. g. earth fault or short circuit of the motor phases) may cause a blocking
me. In this case, the error can be reset only aer the blocking me has elapsed. An acve
blocking me is displayed via bit 14 in the inverter status word 0x2831.
The "Error codes, causes and remedies" table gives the blocking me (if available) for each
error. This table also shows whether mains switching is required for the error reset. ^ 290
Parameter
Address Name / seng range / [default seng] Informaon
0x2631:004
(P400.04)
Funcon list: Reset fault
(Funcon list: Reset fault)
•
Further possible sengs: 4T
rigger list ^ 52
Assignment of a trigger for the "Reset fault" funcon.
Trigger = FALSE↗TRUE (edge): The acve error is reset (acknowledged) if
the err
or condion no longer exists and the error is reseable.
Trigger = FALSE: no acon.
12 Digital input 2 State of X3/DI2, taking an inversion set in 0x2632:002 (P411.02) into
consideraon.
