Action Yes No
Step 3
Check the auto connector end of the option previously installed below the
staple finisher.
Is it free of damage?
Go to step 4. Replace the upper
interface cable of the
output option
previously installed
under the staple
finisher.
Step 4
Check the lower interface cable. If damaged, then replace the lower
interface cable. Go to “Stapler lower interface cable removal” on
page 484.
Reseat the cable (J15) on the controller PCBA, then POR the machine.
Does the error remain?
Go to step 5. The problem is solved.
Step 5
Open the left and top covers. Check the beacon LED. If damaged, then
replace the staple finisher assembly. Go to “Staple finisher assembly
removal” on page 461.
Reseat the cable (J21) on the controller PCBA and reseat the connector
on the beacon LED end. POR the machine.
Does the error remain?
Go to step 6. The problem is solved.
Step 6
Reseat the cable (J12) on the controller PCBA, then POR the machine.
Does the error remain?
Go to step 7. The problem is solved.
Step 7
Check the sensor (finisher bin media present) and do the following:
• check for damage
• move the sensor flag and check if it toggles properly
Is the above component ok?
Go to step 8. Replace the sensor
(finisher bin media
present). Go
to
“Sensor
(finisher bin media
present) removal” on
page 480.
Step 8
Reseat all connectors on the controller PCBA.
Does the error remain?
Replace the controller
PCBA. Go to “Stapler
controller PCBA
removal” on page
486.
If the error persists,
then replace the staple
finisher. Go to “Staple
finisher assembly
removal” on page
461.
The problem is solved.
4063
Diagnostic information
217
