• “OUTPUT BIN TESTS” on page 228
•
“FINISHER TESTS” on page 229
• “BASE SENSOR TEST” on page 231
• “DEVICE TESTS” on page 231
•
“PRINTER SETUP” on page 232
• “EP SETUP” on page 234
•
“REPORTS” on page 236
• “EVENT LOG” on page 237
• “Exit Diags” on page 238
The Diagnostics menu group contains the settings and operations used while manufacturing and servicing the printer.
Entering diagnostics mode
1 Turn off the printer.
2 Press and hold 3 and 6.
3 Turn on the printer.
4 Hold the buttons until the splash screen appears.
5 Select
Exit Diags to exit Diagnostics mode and return to the printer home screen.
REGISTRATION
These settings adjust the margins of the black plane.
To set the Registration:
1 Print a Quick test page.
a From the Diagnostics menu, navigate to:
REGISTRATION
> Quick Test
b Retain this page to determine the changes you need to make to the margin settings. The alignment diamonds
in the margins should touch the margins of the page.
The Quick test page contains the following information:
• Printer registration settings
• Code levels
• Alignment diamonds at the top, bottom, and each side
• Horizontal lines for skew adjustment
• General printer information, including current page count, installed memory, processor speed, serial
number, engine ID, and controller board ID
2 Change the value of any of the margin settings.
Top Margin -25 to +25 Increasing the value moves the image down the page. Always adjust the
top before the bottom margin.
Bottom Margin -20 to +20 Increasing the value moves the image toward the top of the page.
