Connector Connects to Pin no. Signal
J21 Main motor 1 XPORT_HALL_U_C
2 XPORT_HALL_V_C
3 XPORT_HALL_W_C
4 XPORT_FG_C
5 GND
6 +5V_SW
7 XPORT_WIND_U_C
8 XPORT_WIND_V_C
9 XPORT_WIND_W_C
J24 Fuser drive motor 1 FUSER_HALL_U_C
2 FUSER_HALL_V_C
3 FUSER_HALL_W_C
4 FUSER_FG_C
5 GND
6 +5V_SW
7 FUSER_WIND_U_C
8 FUSER_WIND_V_C
9 FUSER_WIND_W_C
J27 Fuser sensor/smart chip 1 S_NAR_MEDIA*_C
2 GND
3 A_SLAB_THERM1_C
4 BELT*_C
5 A_SLAB_THERM2_C
6 +5V_SW
7 A_BR_THERM_C
8 S_EXITSNS*_C
9 S_CART_3V
10 S_FUSER_SCL_C
11 S_FUSER_SDA_C
12 not used
4063
Component locations
516
