Lexmark MS81 Series - Page 536

Assembly 2: Paper path
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7602 1 1 Upper redrive See
“Upper redrive
removal” on page 325.
2 40X7588 1 1 Fuser access door (belt fuser printers only) See “Fuser access door
removal” on page 318.
2 40X8399 1 1 Fuser access door (hot roll fuser printers only) See “Fuser access door
removal” on page 318.
3 40X7587 1 1 Inner guide deflector See “Inner guide
deflector removal” on
page 285.
4 40X7585 1 1 Recoil spring N/A
5 40X7584 1 1 Duplex exit diverter See “Duplex exit diverter
removal” on page 282.
6 40X7583 1 1 Media turn guide See “Media turn guide
removal” on page 295.
7 40X7586 1 1 Media vertical guide See “Media vertical guide
removal” on page 296.
