Lexmark MS81 Series - Page 540

Assembly 4: Electronics
Asm-index P/N Units/mach Units/FRU Description
Removal
procedure
1 40X7694 1 1 LVPS (universal) See “LVPS
removal” on
page 357.
2 40X7685 1 1 Toner level / imaging unit high voltage contact See “HVPS
removal” on
page 356.
3 40X7688 1 1 Input sensor cable N/A
4 40X7578 1 1 HVPS See “HVPS
removal” on
page 356.
5 40X7686 1 1 Sensor (toner density)
Includes shutter and cable
See “Transfer roller
right
arm
removal”
on page 309.
6 40X7606 1 1 Transfer roller right arm See “Transfer roller
right
arm
removal”
on page 309.
7 40X7699 1 1 HVPS/toner cartridge fan cable N/A
8 40X7582 1 1 Transfer roller See “Transfer roller
removal” on
page 312
.
9 40X7605 1 1 Transfer roller left arm with cable See
“Transfer roller
left arm with cable
removal” on
page 308.
10 40X8365 1 1 Printhead access cover See “Laser
printhead
removal” on
page 286.
11 40X7607 1 1 Sensor (input) See “Sensor (input)
removal” on
page 305.
12 40X7693 1 1 Sensor (control panel interlock)
Includes bracket and cable
See “Sensor
(control panel
interlock)
removal” on
page 350.
13 40X7570 1 1 Controller board (2.4” display printers only) See “Controller
board removal” on
page 340.
13 40X7571 1 1 Controller board (4.3” tilting display printers only) See “Controller
board removal” on
page 340.
4063
Parts catalog
540
