Assembly 8: Control panel
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X7700 1 1 2.4" LCD control panel
N/A
1 40X7701 1 1 4.3" touch screen control panel See “Control panel
removal (4.3‑inch
screen, 7‑inch screen)”
on page 372.
1 40X7875 1 1 7" touch screen control panel See
“Control panel
removal (4.3‑inch
screen, 7‑inch screen)”
on page 372.
2 40X7737 1 1 Control panel board (2.4” display only) See “Control panel board
(2.4‑inch tilting display)
removal” on page 378
.
3 40X7741 1 1 Control panel buttons (2.4” display only)
N/A
4 40X7735 1 1 Control panel board (4.3” tilting display only) See “Control panel board
(4.3‑inch tilting display)
removal” on page 381
.
5 40X8042 1 1 Control panel board (7” tilting display only) See
“Control panel board
(4.3‑inch tilting display)
removal” on page 381
.
6 40X8537 1 1 4.3" tilting display See
“4.3‑inch tilting
display removal” on
page 360.
7 40X8661 1 1 Control panel buttons (4.3” and 7” tilting
displays only)
N/A
8 40X8538 1 1 7" tilting display See “7‑inch
tilting display
removal” on page 363.
9 40X7729 1 1 Control panel latch See “Control panel latch
removal” on page 389.
10 40X7731 1 1 Torsion spring N/A
11 40X7681 1 1 Control panel front cover See “Control panel front
cover removal” on
page 387.
12 40X7704 1 1 USB cable N/A
13 40X7730 1 1 Torsion spring N/A
14 40X7702 1 1 Speaker cable N/A
15 40X9079 1 1 Control panel speaker N/A
16 40X8334 1 1 Control panel left bezel (MS810n) See “Control panel left
bezel removal” on
page 390.
