Assembly 11: 250-sheet tray option
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8160 1 1 250-sheet tray option upper interface cable See
“Drawer upper
interface
cable
removal” on
page 403
2 40X8156 1 1 Sensor (pass through) See
“Sensor (drawer pass
through) removal ” on
page 408
3 40X8158 1 1 Sensor (pick) See “Sensor (pick) removal”
on page 410
4 40X7592 1 1 Sensor (pick roller position) See “Sensor (pick roll
position) removal ” on
page 399
5 40X7593 1 1 Pick roller See “Drawer pick roller
removal ” on page 399
6 40X8159 1 1 250-sheet tray option lower interface cable See “Drawer lower
interface
cable
removal” on
page 404
7 40X7713 1 1 Separation roller See “Media tray separation
roller removal” on page
398
8 40X8154 1 1 250-sheet tray front cover See “Media tray front cover
removal” on page 398
9 40X8153 1 1 250-sheet tray See “Media tray assembly
removal” on page 398
10 40X8157 1 1 250-sheet tray option transport motor See “Drawer transport
motor removal” on
page 407
11 40X7591 1 1 Media feeder See “Drawer media feeder
removal ” on page 405
12 40X8155 1 1 250-sheet tray option controller PCBA See “Drawer controller
PCBA removal” on page
402
4063
Parts catalog
558
