Assembly 14: High capacity input tray option 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8178 1 1 Sensor (HCIT pick) with cable See
“Sensor (HCIT pick) removal” on
page 433
2 40X8177 1 1 Sensor (HCIT media low) with flag See “Sensor (HCIT media low) with
flag removal” on page 430
3 40X8174 1 1 HCIT option media feeder See “HCIT media feeder removal” on
page 434
4 40X8180 1 1 HCIT option interface cable See “HCIT drawer assembly interface
cable removal” on page 429
5 40X8173 1 1 HCIT option controller PCBA See “HCIT controller PCBA removal”
on page 424
6 40X8179 1 1 HCIT option lift drive motor See “HCIT lift drive motor removal” on
page 427
7 40X8169 1 1 HCIT option right cover See “HCIT drawer assembly right
cover removal” on page 422
8 40X7592 1 1 Sensor (HCIT pick roller position) See “Sensor (pick roll position)
removal” on page 431
9 40X7593 1 1 Pick roller See “HCIT pick arm assembly
removal” on page 418
10 40X8171 1 1 HCIT front cover See “HCIT front cover removal” on
page 416
11 40X7713 1 1 Separation roller See “HCIT separator roll assembly
removal” on page 415
12 40X8176 1 1 HCIT media guide See “HCIT media guide removal” on
page 415
13 40X8167 1 1 HCIT option left cover See “HCIT drawer assembly left cover
removal” on page 420
