LSIS S100 User Manual

116
Learning Basic Features
Group
Code
Name
LCD Display
Parameter Setting
Setting Range
Unit
82
Digital input
P2P In D
0
–12,000
bit
85
Analog output
P2P Out AO1
0
0–0x7F
%
88 Digital output P2P Out DO 0
0–0x03
bit
USF
01 User function 1 User Func1 0
0–28
-
02 User function input 1-A User Input 1-A 0
0–0xFFFF
-
03 User function input 1-B User Input 1-B 0 0–0xFFFF -
04 User function input 1-C User Input 1-C 0 0–0xFFFF -
05 User function output 1 User Output 1 0
-32767–32767
-
06 User function 2 User Func2 0
0–28
-
07 User function input 2-A User Input 2-A 0
0–0xFFFF
-
08 User function input 2-B User Input 2-B 0
0–0xFFFF
-
09 User function input 2-C User Input 2-C 0
0–0xFFFF
-
10 User function output 2 User Output 2 0
-32767–32767
-
11 User function 3 User Func3 0
0–28
-
12 User function input 3-A User Input 3-A 0
0–0xFFFF
-
13 User function input 3-B User Input 3-B 0
0–0xFFFF
-
14 User function input 3-C User Input 3-C 0
0–0xFFFF
-
15 User function output 3 User Output 3 0
-32767–32767
-
16 Uer function 4 User Func4 0
0–28
-
17 User function input 4-A User Input 4-A 0
0–0xFFFF
-
18 User function input 4-B User Input 4-B 0 0–0xFFFF -
19 User function input 4-C User Input 4-C 0 0–0xFFFF -
20 User function output 4 User Output 4 0
-32767–32767
-
21 User function 5 User Func5 0
0–28
-
22 User function input 5-A User Input 5-A 0
0–0xFFFF
-
23 User function input 5-B User Input 5-B 0
0–0xFFFF
-
24 User function input 5-C User Input 5-C 0
0–0xFFFF
-
25 User function output 5 User Output 5 0
-32767–32767
-
26 User function 6 User Func6 0
0–28
-
27 User function input 6-A User Input 6-A 0
0–0xFFFF
-
28 User function input 6-B User Input 6-B 0
0–0xFFFF
-
29 User function input 6-C User Input 6-C 0
0–0xFFFF
-
30 User function output 6 User Output 6 0
-32767–32767
-
31 User function 7 User Func7 0
0–28
-
32 User function input 7-A User Input 7-A 0
0–0xFFFF
-
