68 User function input14-B User Input 14-B 0
0–0xFFFF
-
69 User function input 14-C User Input 14-C 0
0–0xFFFF
-
70 User function output14 User Output 14 0
-32767–32767
-
71 User function 15 User Func15 0
0–28
-
72 User function input 15-A User Input 15-A 0
0–0xFFFF
-
73 User function input 15-B User Input 15-B 0
0–0xFFFF
-
74 User function input 15-C User Input 15-C 0
0–0xFFFF
-
75 User function output 15 User Output 15 0
-32767–32767
-
76 User function 16 User Func16 0
0–28
-
77 User function input 16-A User Input 16-A 0
0–0xFFFF
-
78 User function input 16-B User Input 16-B 0
0–0xFFFF
-
79 User function input 16-C User Input 16-C 0
0–0xFFFF
-
80 User function output 16 User Output 16 0
-32767–32767
-
81 User function 17 User Func17 0 0–28 -
82 User function input 17-A User Input 17-A 0 0–0xFFFF -
83 User function input 17-B User Input 17-B 0
0–0xFFFF
-
84 User function input 17-C User Input 17-C 0
0–0xFFFF
-
85 User function output 17 User Output 17 0
-32767–32767
-
86 User function 18 User Func18 0
0–28
-
87 User function input 18-A User Input 18-A 0
0–0xFFFF
-
88 User function input 18-B User Input 18-B 0
0–0xFFFF
-
89 User function input 18-C User Input 18-C 0
0–0xFFFF
-
90 User function output 18 User Output 18 0
-32767–32767
-
User Sequence Setting Details
Display the parameter groups related to a user sequence.
USS-01 User Seq Con
Set Sequence Run and Sequence Stop with the keypad.
Parameters cannot be adjusted during an operation. To adjust parameters,
the operation must be stopped.
USS-02 User Loop Time
Set the user sequence Loop Time.
User sequence loop time can be set to 0.01s/0.02s/ 0.05s/0.1s/0.5s/1s.
USS-11–28
Link UserOut1–18
Set parameters to connect 18 Function Blocks. If the input value is 0x0000,
an output value cannot be used.
To use the output value in step 1 for the frequency reference (Cmd
Frequency), input the communication address (0x1101) of the Cmd
frequency as the Link UserOut1 parameter.
