RS-485 Communication Features
Comm. Address Parameter Scale Unit Assigned content by bit
0h0315
DC Link voltage
1
V
-
0h0316
Output power
0.1
kW
-
0h0317
Output torque
0.1
%
-
0h0318
PID reference
0.1
%
-
0h0319
PID feedback
0.1
%
-
0h031A
Display the
number of poles
for the 1
st
motor
- -
Displays the number of poles for the first
motor
0h031B
Display the
number of poles
for the 2
nd
motor
- -
Displays the number of poles for the 2nd
motor
0h031C
Display the
number of poles
for the selected
motor
- -
Displays the number of poles for the selected
motor
0h031D
Select Hz/rpm
-
-
0: Hz, 1: rpm
0h031E
- 0h031F
Reserved - - -
0h0320
Digital input
information
BI5
Reserved
-
-
B7
Reserved
B6
P7(I/O board)
B5
P6(I/O board)
B4
P5(I/O board)
B3
P4(I/O board)
B2
P3(I/O board)
B1
P2(I/O board)
B0
P1(I/O board)
0h0321
Digital output
information
- -
BI5
Reserved
-
Reserved
B4
Reserved
B3
Reserved
B2
Reserved
B1
Q1
B0
Relay 1
0h0322
Virtual digital input
information
- -
B15
Reserved
-
Reserved
B8
Reserved
B7
Virtual DI 8(COM-77)
B6
Virtual DI 7(COM-76)
B5
Virtual DI 6(COM-75)
B4
Virtual DI 5(COM-74)
B3
Virtual DI 4(COM-73)
