Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
32
50
0h1820 PID output scale PID Out Scale 0.1-1000.0(%) 100.0 X O I/P -
34
50
0h1822
PID controller
motion
frequency
Pre-PID Freq
0.00-
Maximum
frequency(Hz)
0.00 X O I/P -
35
50
0h1823
PID controller
motion level
Pre-PID Exit 0.0-100.0(%)
0.0 X O I/P -
36
50
0h1824
PID controller
motion delay
time
Pre-PID Delay 0-9999(s)
600 O O I/P -
37
50
0h1825
PID sleep mode
delay time
PID Sleep DT 0.0-999.9(s)
60.0 O O I/P -
38
50
0h1826
PID sleep mode
frequency
PID Sleep
Freq
0.00-
Maximum
frequency(Hz)
0.00 O O I/P -
39
50
0h1827
PID wake-up
level
PIDWakeUp
Lev
0-100(%)
35 O O I/P -
40
50
0h1828
PID wake-up
mode setting
PID WakeUp
Mod
0
Below
Level
0:Below
Level
O O I/P -
1
Above
Level
2
Beyond
Level
42
50
0h182A
PID controller
unit selection
PID Unit Sel
0
%
0:% O O I/P -
1
Bar
2
mBar
3
Pa
4
kPa
5
Hz
6
rpm
7
V
8
I
9
kW
10
HP
11
℃
12
℉
43
50
0h182B PID unit gain PID Unit Gain
0.00-
300.00(%)
100.00 O O I/P -
44
50
0h182C PID unit scale
PID Unit
Scale
0
x100
2:x 1 O O I/P -
1
x10
2
x 1
3
x 0.1
4
x 0.01
