Table of Functions
Code
Comm.
Address
Name LCD Display Setting Range
Initial
Value
Property* V/F SL Ref.
16 AND
17 OR
18 XOR
19 ANDOR
20 SWITCH
21 BITTEST
22 BITSET
23 BITCLEAR
24 LOWPASSFILTER
25 PI_CONTORL
26 PI_PROCESS
27 UPCOUNT
28 DOWNCOUNT
02 0h1E02
User function
input1-A
User Input1-
A
0-0xFFFF 0 X O I/P p.115
03 0h1E03
User function
input1-B
User Input1-
B
0-0xFFFF 0 X O I/P p.115
04 0h1E04
User function
input1-C
User Input1-
C
0-0xFFFF 0 X O I/P p.115
05 0h1E05
User function
output1
User
Output1
-32767-32767 0 O I/P p.115
06 0h1E06 User function 2 User Func2
0 NOP
0: NOP X O I/P p.115
1 ADD
2 SUB
3 ADDSUB
4 MIN
5 MAX
6 ABS
7 NEGATE
8 MPYDIV
9 REMAINDER
10 COMPARE-GT
11 COMPARE-GEQ
12
COMPARE-
EQUAL
13
COMPARE-
NEQUAL
