LSIS SV-iS7 series User Manual

Chapter 8 Table of Functions
G
8-9
No. Comm. No. Function Display Name Setting Range Initial Value
Shift in
Operation
Control Mode
V/F
SL
VC
SLT
VCT
61 -
Load Spd
Gain
revolution display
gain
1 ~ 6000.0 [%] 100.0 O O O O X X
62 -
Load Spd
Scale
revolution display
scale
0 x 1
0:x 1 O O O O X X
1 x 0.1
2 x 0.01
3 x 0.001
4 x 0.0001
63 0h133F Load Spd Unit
revolution display
unit
0rpm
0:rpm O O O O O O
1mpm
64 0h1340 FAN Control cooling fan control
0 During Run
0 : During
Run
O O O O X X
1 Always ON
2 Temp Control
65 0h1341
U/D Save
Mode
up/down
Operation
frequency saving
0 No
0 : No O O O O X X
1 Yes
66 0h1342 On/Off Ctrl Src -
0 None
0 : None X O OOOO
1 V1
2 I1
3 V2
4 I2
67 0h1343 On-C Level
Output contact
point ON level
10 ~ 100 [%] 90.00 X O OOOO
68 0h1344 Off-C Level
Output contact
point OFF level
-100.00
~
output contact
point ON level [%]
10.00 X O OOOO
70 0h1346 Run En Mode
safety operation
selection
0 Always Enable
0 :
A
lways
Enable
X O OOOO
1 DI Dependen
t
71
Note14)
0h1347 Run Dis Stop
safety operation
stop method
0 Free-Run
0 : Free-Run X O O O O O
1
Q
-Sto
p
2
Q
-Sto
p
Resume
72 0h1348 Q-Stop Time
safety operation
decelerating time
0 ~ 600.0 [s] 5.0 O O O O O O
74 0h134A RegenAvd Sel
Selection of
regeneration and
avoidance function
for press
0 No
No X O OOOO
1 Yes
75 0h134B
RegenAvd
Level
Operational
Voltage level of
regeneration anc
avoidance for
press
200V: 300 ~ 400 350V
X O O O X X
400V: 600 ~ 800 700V
