LSIS XEC-DP64H User Manual

Chapter 1 General
1- 8
1.4.3
Allocation of compact type (S/H type) input signal
In case of compact standard/high-end type, external input signal for built-in positioning is allocated as
follows
(1) I/O terminal block array
Array of XGB transistor output type basic unit is as figure below.
Input (P0)
Output (P4)
* based on XBC-DN30S
* based on XBC-DN32H
