LSIS XEC-DP64H User Manual

Appendix 1 List of Error Codes
APP.1- 6
Error
code
Description
Operation
Countermeasures
346
Position synchronic command is unavailable without origin
of main axis set.
Stop
Check whether main axis was without origin set at the time of
position synchronic command.
347
There is an error of setting main/sub axis of position
synchronic command.
Stop
Check whether main axis of position synchronic command was not
set equally with command axis.
351
Speed synchronic command is unavailable during
operation.
Operation
Check whether an axis was not operating at the time of speed
synchronic command.
352
Speed synchronic command is unavailable in ‘no output’
status.
Stop
Check whether an axis was not in ‘no output’ status at the time of
speed synchronic command.
353 Speed synchronic command is unavailable with M code On
Stop
Check whether M code signal of an axis was not On at the time of
speed synchronic command.
355
There is an error of main/sub axis setting of speed
synchronic command.
1) main/ sub axis were set equally
2) set of main axis >5
Stop
Check whether the main axis of speed synchronic command was
not set equally with command axis.
356
There is an error of synchronization ratio setting of speed
synchronic command
Stop
Check whether the synchronization ratio of speed synchronic
command was not set between 0~10,000.
357 Delay time setting error Stop Check whether delay time was set between 1 ~ 10ms.
361
Position override command is unavailable in any other
status but ‘busy’
Stop
Check whether an axis did not stop at the time of position override
command.
362 Position override command is unavailable during dwelling Stop
Check whether an axis was not dwelling at the time of position
override command.
363
Position override command is unavailable in any other
status but positioning operation.
Operation
Check whether an axis was not operating by position control at the
time of position override command.
364
Position override command is unavailable for an axis of
linear interpolation operation.
Operation
Check whether an axis was not in linear-interpolation operation at
the time of position override command.
366
Position override command is unavailable for a synchronic
operation sub axis.
Operation
Check whether an axis was not operating as a sub axis of
synchronic operation at the time of position override command.
371
Speed override command is unavailable in any other status
but ‘busy’.
Stop
Check whether an axis did not stop at the time of speed override
command.
372 Out-of speed override range error Stop
Re-set the speed of speed override command equal to or lower
than the max speed set in the basic parameter.
373
Speed override command is unavailable to an sub axis of
linear interpolation operation.
Operation
Check whether an axis was not operating as a sub axis of linear
interpolation at the time of speed override command.
375
Speed override command is unavailable to an sub axis of
synchronic operation
Operation
Check whether an axis was not operating as a sub axis of
synchronic operation at the time of speed override command.
377 Speed override command is unavailable in a DEC section Operation
Check whether an axis was not decelerating for stoppage at the
time of speed override command.
381
Positioning speed override command is unavailable in any
other status but ‘operation’.
Stop
Check whether an axis did not stop at the time of positioning speed
override command.
382
Positioning speed override command is unavailable in any
other operation but ‘positioning operation’
Stop
Check whether an axis was not in speed control operation at the
time of positioning speed override.
383
Out of speed override range error of positioning sped
override command
Stop
Check whether the speed of positioning speed override command
was not equal to or lower than the max speed set in parameter.
