LSIS XEC-DP64H User Manual

Chapter 3 Before positioning
3- 27
(2) Setting parameter
• Positioning parameter setting window is classified into basic parameter and Home parameter.
• Each item can be set independently.
• For detail setting of basic parameter, refer to 3.2.3.
• For detail setting of Home parameter, refer to 3.2.4.
Type Item Description
Basic parameters
Positioning Set whether to use positioning function.
Pulse output level Set pulse output mode (Low/High Active).
Bias speed Set the initial start speed for early operation.
Speed limit Set the max speed settable in positioning operation.
ACC/DEC No.1 Time setting of ACC/DEC section No.1
ACC/DEC No.2 Time setting of ACC/DEC section No.2
ACC/DEC No.3 Time setting of ACC/DEC section No.3
ACC/DEC No.4 Time setting of ACC/DEC section No.4
S/W upper limit Set upper limit within a machine’s operation range
S/W lower limit Set lower limit within a machine’s operation range
Backlash compensation
amount
Set compensation amount of tolerance in which a machine is not operated due
to wear when rotation direction is changed.
S/W upper/lower limits
during constant speed
operation
Set whether to detect or not S/W upper/lower limits during constant speed
operation
Use upper/lower limits Use or not
Origin/Manual
parameters
Home Return method Set home return method
Home Return direction Set home return direction
Origin address Set origin address
Origin compensation amount Set origin compensation amount
Home Return high speed Set high speed for home return
Home Return low speed Set low speed for home return
Home Return accelerating
time
Set accelerating time for home return
Home Return decelerating
time
Set decelerating time for home return
Dwell time
Set a time required to remove remaining bias counter immediately after
positioning ends
Jog high speed Set high speed for jog operation
Jog low speed Set low speed for jog operation
Jog accelerating time Set accelerating time for jog operation
Jog decelerating time Set decelerating time for jog operation
Inching speed Set speed for inching operation
< Positioning parameter setting item >
