Chapter 3 Before positioning
3- 55
(2) Data Area for Positioning Setting
(a) In case of XBM/XBC
Variables
Device Area
Status
Axis X Axis Y
Address Properties
A
ddress Properties
Bias speed K0450 Double word K0490 Double word Sets bias speed.
Speed limit K0452 Double word K0492 Double word Sets maximum speed limit.
Acceleration time 1 K0454 Word K0494 Word Sets acceleration time 1.
Deceleration time 1 K0455 Word K0495 Word Sets deceleration time 1.
Acceleration time 2 K0456 Word K0496 Word Sets acceleration time 2.
Deceleration time 2 K0457 Word K0497 Word Sets deceleration time 2.
Acceleration time 3 K0458 Word K0498 Word Sets acceleration time 3.
Deceleration time 3 K0459 Word K0499 Word Sets deceleration time 3.
Acceleration time 4 K0460 Word K0500 Word Sets acceleration time 4.
Deceleration time 4 K0461 Word K0501 Word Sets deceleration time 1
Upper limit of
software
K0462 Double word K0502 Double word
Sets upper limit value of
software.
Lower limit of
software
K0464 Double word K0504 Double word
Sets lower limit value of
software.
Backlash correction K0466 Word K0506 Word
Sets backlash correction
value.
Origin address K0469 Double word K0509 Double word
Sets origin address for origin
return.
High speed of origin
return
K0471 Double word K0511 Double word
Sets high speed for origin
return.
Low speed of origin
return
K0473 Double word K0513 Double word
Sets low speed for origin
return.
A
cceleration time for
origin return
K0475 Word K0515 Word
Sets acceleration time for
origin return
Deceleration time for
origin return
K0476 Word K0516 Word
Sets deceleration time for
origin return
Dwell time for origin
return
K0477 Word K0517 Word
Sets dwell time for origin
return
Jog high speed K0479 Double word K0519 Double word
Sets high speed for jog
operation.
Jog low speed K0481 Double word K0521 Double word
Sets low speed for jog
operation
Jog acceleration time K0483 Word K0523 Word
Sets acceleration time for jog
operation
Jog deceleration time K0484 Word K0524 Word
Sets deceleration time for jog
operation
Inching speed K0485 Word K0525 Word
Sets operation speed for
inching operation.
