LSIS XEC-DP64H User Manual

Chapter 3 Before positioning
3- 57
(3) Status Monitoring and Commanding Flag by Operation Step
(a) In case of XBM/XBC (Step 01)
Variables
Device area
Status
Axis X Axis Y
properties
Address Address
Step 01 target position K0530 K0830
Double
word
Step 01 operation speed K0534 K0834
Double
word
Step 01 dwell time K0536 K0836 Word
Step 01 M code number K0537 K0837 Word
Step 01 operation method K05380 K08380 Bit
Step 01 control method K05381 K08381 Bit
Step 01 operation pattern
(Low)
K05382 K08382
Bit
Step 01 operation pattern
(High)
K05383 K08383
Bit
Step 01 coordinates K05384 K08384 Bit
Step 01 acc./dec. number
(Low)
K05386 K08386
Bit
Step 01 acc./dec. number
(High)
K05387 K08387
Bit
Step 01 coordinates K0539 K0839 Word
