215651 123 Revision B
Every 100 Hours
Lubricate the following components every 100 hours unless otherwise stated.
NOTE:
Use High Temperature Extreme Pressure (EP2) Performance with 1% max molybdenum disulphide (NLGI Grade 2) lithium
base unless otherwise specified.
(
&
%
$
'
Figure 5.10: Every 100 Hours
A - Knife Drive Box (Check Oil Level with Top of Knife Drive Box in Horizontal Position)
B - Dipstick (Level between Lower Hole and End of Dipstick)
C - Upper Cross Auger Bearing
D - Reel Drive Chain
E - Hydraulic Couplers (Use WD40
®
or Equivalent)
MAINTENANCE AND SERVICING
