MacDon R85 - Page 69

214366 52 Revision A
1005195
A
B
Figure 3.45: Hose Bundle
1. Disengage and rotate lever (A) counterclockwise to the
UP position.
2. Remove cap (B) securing the electrical connector to
the frame.
1005196
A
Figure 3.46: Hose Bundle
3. Move hose bundle (A) from the windrower, and rest the
bundle on the header.
OPERATION
