OPERATION145

C0032895

T310TRANSMISSIONRATIOS

Ratios

Gear(MainBox)LOHI

1/6

13.812.67

2/7

10.051.94

3/8

7.181.39

4/9

5.171.00

5/10

3.750.73

R/R

14.732.85
