8INTRODUCTION

TheAllisonMDtransmissionidenticationplateislocatedontherearrightsideofthe

maincase,nearthelowerend.

C0032624

AllEaton®Fuller®transmissionidenticationplatesarelocatedonthefrontleftsideof

themaincase.

C0032625

TheMACKcarrierassemblyserialnumberislocatedonthefrontrightsideofthehousing.

C0032626
