Mack,EmissionsSolution175

DieselExhaustFluid(DEF)Consumption

DEFconsumptionisrelatedtofuelconsumption.Agaugemuchlikeafuelgaugewill

indicatethelevelofDEFinthetank.ADEFlow-levelwarningwillactivatewhenDEF

islow.IfadriverrunsoutofDEFcompletely,vehiclepowerwillbereduced.Whenthe

DEFtankisrelled,theenginewillresumenormalpower.

Note:DEFtanksaresizedtooptimizewithfuelcapacityrequirements.

DieselExhaustFluid(DEF)Availability

ForDEFavailabilitypleasecontactyourlocalMACKdealer.
