MAINTENANCEANDLUBRICATION221
LowerConnector:
ElectricalConnection
Fusedamps
BackUpLampSignal
15A
DashMounted12VBatterySwitch**
20A
DashMounted12VIgnitionSwitch**
20A
PTO1&PTO2Signals
SpeedControlInput
SetSpeedInput
ResumeSpeedInput
ThrottleSignal
J1587/1708DiagnosticBusConnectors(-/+)
RH&LHTurnLampSignals
RH&LHTurn/StopLampSignals
BufferedMPH&RPMOutputSignals
DashMountedBodyLampSignal*
Spare:14Gauge(5)***
Spare:16Gauge(1)***
*Aninputsignal(12V)connectionisincludedinBodyLinkiftheBodyLampisordered.
**OutputpowerisincludedinBodyLinkIIifauxiliaryorextradashmountedbatteryand
ignitionpowerdashrockerswitchesareordered.
***Spareconnectorsaretypicallyusedtowireuniquebodybuildercontrolsintothedash
area.
5-WayLightingConnector:
•ParkingLamps
•ReverseLamps
•LeftStop-Turn
•RightStop-Turn
•GroundConnections
