42INSTRUMENTSANDCONTROLS
PanelB(SCR)
W3061948
6.AftertreatmentDEFLevelGauge21.EngineOverSpeedIndicator(Red)
7.GradeGripperIndicator(Amber)22.TrailerAnti-LockBrakeSystem
(ABS)Indicator(Amber)
8.Pre-HeatStartIndicator(Amber)(If
Equipped)
23.CruiseControlOnIndicator(Green)
9.CheckTransmissionIndicator
(Amber)
24.PowerT ake-OffOperatingIndicator
(Green)
10.MalfunctionIndicatorLamp(MIL)
(Amber)
25.RightTurnSignalIndicator(Green)
11.CheckLamp(Amber)26.BendixAdaptiveCruiseControl
(ACC)Indicator(Red)
12.HighBeamsIndicator(Blue)27.ReverseIndicator(Amber)
13.ParkingBrakeIndicator(Red)28.AutomaticTractionControl(ATC)
Indicator(Amber)
14.LeftTurnSignalIndicator(Green)29.NeutralIndicator(Amber)
15.EngineShutdownIndicator(Red)30.FastenSeatBeltWarningIndicator
(Red)
16.AftertreatmentDEFLowLevel
Indicator(DEF)
31.HESTIndicator(HighExhaust
Temperature)
17.Anti-LockBrakeSystem(ABS)
Indicator(Amber)
32.FuelGauge
18.LowCoolantLevelIndicator(Amber)33.Speedometer
19.Co-Pilot®
34.Tachometer
20.WaterinFuelIndicator(Amber)(If
Equipped)
