PanelB(DPF)
W3062227
6.CoolantTemperatureGauge21.EngineOverSpeedIndicator(Red)
7.IntegratedTemp-A-StartIndicator
(Amber)(IfEquipped)
22.TrailerAnti-LockBrakeSystem(ABS)
Indicator(Amber)
8.Pre-HeatStartIndicator(Amber)(If
Equipped)
23.CruiseControlOnIndicator(Green)
9.CheckTransmissionIndicator(Amber)24.PowerTake-OffOperatingIndicator
(Green)
10.MalfunctionIndicatorLamp(MIL)
(Amber)
25.RightTurnSignalIndicator(Green)
11.CheckLamp(Amber)26.BendixAdaptiveCruiseControl(ACC)
Indicator(Red)
12.HighBeamsIndicator(Blue)27.ReverseIndicator(Amber)
13.ParkingBrakeIndicator(Red)28.AutomaticTractionControl(A TC)
Indicator(Amber)
14.LeftTurnSignalIndicator(Green)29.NeutralIndicator(Amber)
15.EngineShutdownIndicator(Red)30.FastenSeatBeltWarningIndicator(Red)
16.AirSuspensionLowIndicator(Amber)31.HESTIndicator(HighExhaust
Temperature)
17.Anti-LockBrakeSystem(ABS)
Indicator(Amber)
32.FuelGauge
18.LowCoolantLevelIndicator(Amber)33.Speedometer
